ASTM A210 Boiler Tube Specifications

The table below lists key specifications of ASTM A210 / ASME SA-210 seamless boiler tubes, including applicable standards, sizes, and delivery conditions.

Property Details
StandardsASTM A210 / A210M, ASME SA-210
Outside Diameter12.7 mm to 127 mm (1/2" to 5")
Wall Thickness0.9 mm to 12.7 mm (0.035" to 0.500")
LengthSingle Random, Double Random, Cut Length (up to 25 m)
FormSeamless Tube (Round)
FinishHot-Finished or Cold-Finished
End TypePlain End, Bevelled End
SurfaceBlack, Varnished, or Oiled

ASTM A210 Boiler Tubes Price

ASTM A210 boiler tube pricing is ₹85 and ₹300 per kg or $0.60 to $2.15 per kg. The final price depends on grade selection (A-1 or C), outside diameter, wall thickness, length, order quantity, and current steel market conditions. Cold-finished tubes cost more than hot-finished tubes because of the additional processing and heat treatment steps involved. We provide competitive rates for both project orders and bulk supplies. Contact our sales team with your required size, grade, and quantity for an accurate quotation.

Chemical Composition of ASTM A210 Boiler Tubes

The chemical composition of ASTM A210 / A210M boiler tubes per the standard is given below. Grade C carries higher carbon and manganese for increased strength.

Grade A-1

Carbon C
0.27% max
Manganese Mn
0.93% max
Phosphorus P
0.035% max
Sulphur S
0.035% max
Silicon Si
0.10% min

Grade C

Carbon C
0.35% max
Manganese Mn
0.29% to 1.06%
Phosphorus P
0.035% max
Sulphur S
0.035% max
Silicon Si
0.10% min

Mechanical Properties of ASTM A210 Tubes

The table below lists the minimum mechanical properties of ASTM A210 boiler tubes for both grades. Engineers use these values for pressure rating calculations in boiler design.

415 / 60
MPa (ksi)
Tensile Strength (min)
255 / 37
MPa (ksi)
Yield Strength (min)
30
%
Elongation (min) (2 in. or 50 mm)
79
HRB
Hardness (max)
485 / 70
MPa (ksi)
Tensile Strength (min)
275 / 40
MPa (ksi)
Yield Strength (min)
30
%
Elongation (min) (2 in. or 50 mm)
89
HRB
Hardness (max)
Property Grade A-1 Grade C
Tensile Strength (min)415 MPa (60 ksi)485 MPa (70 ksi)
Yield Strength (min)255 MPa (37 ksi)275 MPa (40 ksi)
Elongation (min) (2 in. or 50 mm, min)30%30%
Hardness (max)79 HRB89 HRB
Request a Quote for ASTM A210 Boiler Tubes. Request a Quote

Equivalent Grades for ASTM A210 Boiler Tubes

ASTM A210 / ASME SA-210 has approximate equivalents across several international standards. The table below provides the equivalent grades for these boiler tubes.

Standard Designation
ASTM / ASME A210 / SA-210 (Gr. A-1, Gr. C)
EN 10216-2 P195GH, P235GH, P265GH
DIN 17175 St 35.8 · St 45.8
GB / T 3087 Grade 10, Grade 20
JIS G3461 STB340 · STB410 · STB440
BS 3059 Pt.1 · 3602 Pt.1

Industrial Applications of ASTM A210 Boiler Tubes

ASTM A210 / ASME SA-210 seamless tubes serve three primary sectors. Their medium-carbon composition and elevated-temperature strength make them suitable for the following applications.

Power Generation and Thermal Plants

ASTM A210 tubes are installed in boiler water walls, economisers, and low-temperature superheaters in coal-fired, gas-fired, and waste-heat recovery power plants operating below 500° Celsius. .

Petrochemical and Refinery Applications

Refinery process heaters and catalytic cracker units use these tubes for fired heater coils and steam generation systems, where medium-carbon steel provides adequate strength at moderate temperatures.

Heat Exchangers and Condensers

SA-210 Grade A-1 and Grade C tubes function as heat transfer elements in shell-and-tube exchangers and surface condensers across industrial and process plant installations.

ASTM A210 Grade A-1 and Grade C Comparison

ASTM A210 covers two grades: Grade A-1 and Grade C. Grade C has higher carbon content (up to 0.35% vs 0.27%) and higher minimum tensile strength (485 MPa vs 415 MPa) compared to Grade A-1. Grade C is selected for higher-pressure boiler service where greater strength is required.

Shipping & Packaging

Main export packaging setup Heavy-duty wooden boxes Packing
Export Packaging Standard

We strictly follow seaworthy export handling standards to protect ASTM A210 Boiler Tubes from transit damage, moisture ingress, and surface contamination during long-distance dispatch.

  • Heavy-duty wooden boxes with moisture barrier lining
  • HDPE stretch film wrapping on all bundles
  • Plastic end caps on threaded and plain-end pipes
  • Silica gel desiccants to minimize moisture exposure
  • ISPM-15 fumigated wooden packaging for export
Bundle Yard Staging Pipe Bundle Yard Staging
Bundle Edge Protection Container End-Cap Protection
Export-Ready Bundles Wrapped Export-Ready Bundles

We Export Worldwide

Sachiya Steel International supplies stainless steel products to major industrial markets across North America, Europe, the Middle East, Asia and Africa with export-ready documentation and logistics support.

  • USA flagUSA
  • Canada flagCanada

Frequently Asked Questions

What is SA-210 Tube made of?+
SA-210 (ASME) / ASTM A210 tubes are made of seamless medium-carbon steel with controlled levels of carbon, manganese, silicon, phosphorus, and sulphur. Grade A-1 has a maximum 0.27% carbon; Grade C allows up to 0.35% carbon.
What is the difference between ASTM A210 Grade A-1 and Grade C?+
Grade C has higher carbon content (up to 0.35% vs 0.27%) and higher minimum tensile strength (485 MPa vs 415 MPa) compared to Grade A-1. Grade C is selected for higher-pressure boiler service where greater strength is required.
What sizes are ASTM A210 Boiler Tubes available in?+
Outside diameters range from 12.7 mm to 127 mm (1/2" to 5"), with wall thicknesses from 0.9 mm to 12.7 mm. We supply single random, double random, and cut lengths up to 25 metres.
What is the SA 210 Gr A1 equivalent in European standards?+
EN 10216-2 is the approximate European equivalent for seamless steel tubes for pressure purposes at elevated temperatures. The older German equivalent was DIN 17175 St 45.8, now superseded.
What is the maximum working temperature for ASTM A210 Tubes?+
ASTM A210 / ASME SA-210 boiler tubes are suitable for service below 500 oCelsius. They're commonly used in water walls, economisers, low-temperature superheaters, and steam pipelines within this temperature range.
Where can I buy ASTM A210 Boiler Tubes?+
Sachiya Steel International supplies ASTM A210 boiler tubes in both Grade A-1 and Grade C from ready stock. Contact us with your required grade, OD, wall thickness, length, and quantity for a quotation and lead time confirmation.
