Specifications of Stainless Steel 410 Sheets

The specifications for Stainless Steel 410 Sheets, including size range, standards and length, are listed in the table below.

Parameter Specification
Standards ASTM A240 / ASME SA240
Size Range 1000 mm to 2000 mm width; custom sizes available
Length 2000 mm, 2440 mm, 3000 mm, 6000 mm, or custom lengths
End Type Sheared / Cut edges
Surface Finish 2B, BA, No.1, No.4, Mirror Finish, Hairline
Form Hot Rolled (HR), Cold Rolled (CR), Sheets, Plates, Coils

Stainless Steel 410 Sheet Sizes

Sachiya Steel stocks 410 stainless steel sheet in these standard and custom dimensions.

Dimension Available Range
Thickness 0.020” to 0.1870” (0.5 mm to 4.75 mm)
Width 12”, 24”, 36”, 48” (300 to 1,220 mm)
Length Up to 6000 mm
Standard Sheet Sizes 12×12 to 48×120
Custom Sizes Available on request

Available Surface Finishes for 410 SS Sheet

410 stainless steel sheet is commonly supplied in 3 surface finishes.

2D finish (cold-rolled, heat-treated, pickled)

No. 4 brushed

BA (bright annealed)

410 Stainless Steel Sheet Price

SS 410 sheet price ranges from ₹135 to ₹185 per kg in India and $1.10 to $2.50 per kg internationally. Pricing depends on thickness, finish, quantity, and specification (AMS 5504 commands a premium over ASTM A240). Contact Sachiya Steel International for current quotations.

SS 410 Sheet Chemical Composition

The table below lists the chemical composition of Type 410 stainless steel sheet (UNS S41000) as a percentage by weight.

Carbon (C)
0.08 – 0.15
Chromium (Cr)
11.5 – 13.5
Manganese (Mn)
1.00 max
Silicon (Si)
1.00 max
Nickel (Ni)
0.75 max
Phosphorus (P)
0.040 max
Sulfur (S)
0.030 max
Iron (Fe)
Balance

Mechanical Properties of 410 Stainless Steel Sheet

The mechanical properties of 410 Stainless Steel Sheet, including elongation and tensile strength, are listed below:

450 / 65
MPa (ksi)
Tensile Strength
205 / 30
MPa (ksi)
Yield Strength
20%
(min)
Elongation
217 HB
Brinell(max)
Hardness
Property Annealed Condition Properties Heat-Treated Condition Properties
Tensile Strength Minimum 450 MPa (65 ksi) Above 690 MPa (100 ksi)
Yield Strength Minimum 205 MPa (30 ksi) Around 550 MPa (80 ksi)
Elongation Minimum 20% Not specified
Hardness Max 217 HB HRC 35 – 43
Request a Quote for 410 Stainless Steel Sheet Request a Quote

Equivalent Grades of Stainless Steel 410 Sheet

Grade 410 sheet is produced worldwide under multiple designations. The table maps equivalent standards.

Standard Designation
UNS S41000
EN / DIN X12Cr13
Werkstoff Nr. 1.4006
JIS G 4304 SUS410
BS 410S21
AFNOR Z12C13
IS 6911 Grade 04Cr13

410 Stainless Steel Sheet Industrial Applications

410 stainless steel sheet serves 4 major industrial segments where strength, wear resistance, and moderate corrosion protection are needed.

🛢️

Oil & Gas and Petrochemical Processing

Grade 410 stainless steel sheet commonly serves in oil and gas systems for components such as valve trims, pump liners, and separator parts.

🍶

Cutlery and Food Processing Equipment

It is widely selected for manufacturing kitchen knives, sanitary cutting blades, and various components used in food processing lines and systems.

⚡

Power Generation and Turbine Components

410 stainless steel sheet is commonly used to manufacture steam turbine blades, nozzle ring components, and various structural fastener plates.

🔧

Industrial Valve and Pump Components

Valve seats, stems, and pump shaft sleeves rely on 410 sheet's combination of hardness and corrosion resistance.

410 vs 304 Stainless Steel Sheet

Compare SS 410 and Stainless Steel 304 sheets for hardness, corrosion resistance, cost, and application suitability to select the right material grade.

Property SS 410 Sheet SS 304 Sheet
Hardness Higher hardness is achievable via heat treatment Lower hardness; not heat treatable for hardening
Corrosion Resistance Moderate; lower than 304 Excellent; suitable for chemical and marine exposure
Nickel Content Up to 0.75% 8.0% – 10.5%
Wear Resistance High; suitable for wear-intensive applications Moderate
Cost Lower cost due to low nickel content Higher cost due to higher nickel content
Best Use Case Wear-resistant parts, valves, fasteners Chemical processing, marine, food-grade applications

410 vs 316 Stainless Steel Sheet

Compare SS 410 and Stainless Steel 316 sheets for structure, corrosion resistance, hardness, and cost to choose the right material for applications.

Property SS 410 Sheet SS 316 Sheet
Microstructure Martensitic Austenitic
Magnetic Properties Magnetic Non-magnetic (in annealed condition)
Heat Treatment Can be hardened by heat treatment Cannot be hardened by heat treatment
Molybdenum Content Not present 2.0% – 3.0%
Corrosion Resistance Moderate Excellent; superior chloride pitting resistance
Best Environment General-purpose, wear-resistant applications Chemical processing and marine environments
Strength/Hardness Higher hardness and strength after heat treatment Lower hardness; not heat hardenable
Cost Lower Higher due to alloying elements
Typical Applications Valves, fasteners, shafts, wear parts Marine components, chemical equipment, pipelines

Shipping & Packaging

Main export packaging setup Heavy-duty wooden boxes Packing
Export Packaging Standard

We strictly follow seaworthy export handling standards to protect stainless steel 410 sheets from transit damage, moisture ingress, and surface contamination during long-distance dispatch.

  • Heavy-duty wooden boxes with moisture barrier lining
  • HDPE stretch film wrapping on all bundles
  • Edge and corner protection with plastic padding
  • Silica gel desiccants to minimize moisture exposure
  • ISPM-15 fumigated wooden packaging for export
shipping preparation Sheet Bundle Yard Staging
Shipping packaging Sheet Bundle Edge Protection
Shipping stock Wrapped Export-Ready Bundles

We Export Worldwide

Sachiya Steel International supplies stainless steel products to major industrial markets across North America, Europe, the Middle East, Asia and Africa with export-ready documentation and logistics support.

  • USA flagUSA
  • Canada flagCanada

Frequently Asked Questions:

What sizes are available for 410 Stainless Steel Sheet?+
Type 410 sheet is stocked in thicknesses from 0.020” to 0.1870” (0.5 to 4.75 mm), widths of 12” to 48” (300 to 1,220 mm), and lengths up to 120” (3,048 mm). Custom dimensions are available on request.
Can 410 Stainless Steel Sheet be heat-treated?+
Yes. Grade 410 is a martensitic grade that responds to quench-and-temper heat treatment. Heat to 925–1010°C, cool quickly in oil or air, then reheat (temper) to 200–600°C. For annealing, hold at 830 to 885°C and furnace-cool.
Which is better for sheet applications: 410 or 304 Stainless Steel?+
410 offers higher hardness and strength at a lower cost. 304 provides better corrosion resistance in wet or chemical environments. Choose based on whether you need better wear resistance or better corrosion protection.
Is 410 Stainless Steel Sheet magnetic?+
Yes. 410 is magnetic in both the annealed and heat-treated conditions because of its body-centred cubic (martensitic) crystal structure.
What is the price of SS 410 Sheet per kg?+
SS 410 sheet price ranges from ₹135 to ₹185 per kg in India and $1.10 to $2.50 per kg internationally. Pricing varies with thickness, size, finish, and order quantity.
What ASTM standard covers 410 Stainless Steel Sheet?+
ASTM A240 / ASME SA-240 is the primary standard. AMS 5504 covers the aerospace variant. ASTM A480 provides general requirements for flat-rolled stainless steel.
Can 410 Stainless Steel Sheet be welded?+
Yes, but preheat to approximately 250°C (480°F) before welding. Post-weld heat treatment prevents cracking. Weld in the annealed condition for best results.
What is the difference between 410 and 410S Stainless Steel Sheet?+
410S is a lower-carbon, non-hardenable variant with improved weldability. Standard 410 can be heat-treated to high hardness; 410S can't. Choose 410S when welding is the primary fabrication method.
