Stainless Steel 310 Pipe Specification
Refer to the following standard technical specifications for Grade 310 pipe, standard, type, size, range and other required information.
| Parameter | Details |
|---|---|
| Standard | ASTM A312, A358 / ASME SA312, SA358 |
| Type | Seamless, ERW (1/2"–24" NB), EFW (6"–100" NB), Welded, Fabricated, LSAW |
| Size Range | 1/8″ NB to 30″ NB (Specialised in Large-Diameter Sizes) |
| Wall Thickness | Standard, XS, XXS (Tailored non-regular sizes available on request) |
| Schedule | SCH 20, 30, 40, STD, 60, 80, 120, 140, 160, XXS |
| Form | Round, Square, Rectangular, Hydraulic, etc. |
| Length | Single Random, Double Random, and Cut-to-Length |
| End Type | Plain End, Bevelled End, Threaded (with Plastic Cap protection) |
Stainless Steel 310 Pipe Sizes
Inventory includes seamless pipes up to 24” NPS and welded forms up to 36” NPS, manufactured according to ASME B36.19M and B36.10M dimensional standards.
This table provides the specific dimensional range for Grade 310 high-temperature pipes.
| Parameter | Range |
|---|---|
| Nominal Pipe Size (NPS) | 1/2" to 36" (DN15 to DN900) |
| Outside Diameter (OD) | 21.3 mm to 914.4 mm |
| Schedules | 5S, 10S, 40S, 80S, 160, XXS |
| Wall Thickness | 0.6 mm to 12.7 mm |
| Standard Lengths | 6-metre single random, 12-metre double random |
| Custom Lengths | Available on request (Cut-to-length) |
Stainless Steel 310 Pipe Price
Stainless steel 310 pipe is priced at approximately ₹700-900/kg in India for standard sizes (SCH 40, seamless). Prices on the international market range from $8 to $15 per kilogram, depending on the outer diameter, wall thickness, and finish.
SS 310 pipe costs roughly 30–50% more than SS 304 and 15–25% more than SS 316 due to higher chromium and nickel content. Final pricing depends on manufacturing type, surface finish, and quantity ordered. Contact Sachiya Steel International for a competitive quotation.
Chemical Composition of Stainless Steel 310 Pipe
The table below lists the chemical composition of TP 310 (UNS S31000) pipe per ASME ASTM A312/SA312.
With an iron balance, this high-alloy composition contains 24.0–26.0% chromium and 19.0–22.0% nickel. It maintains minimal impurities, with a maximum of 1.50% silicon and 0.25% carbon.
Mechanical Properties of SS 310 Pipe
TP 310 pipe meets these minimum mechanical property requirements per ASTM A312/ASME SA312.
This material has a minimum tensile strength of 75 ksi (515 MPa), a minimum yield strength of 30 ksi (205 MPa), and a minimum elongation of 35%. One of these strengths is much higher than the other.
| Property | Imperial | Metric |
|---|---|---|
| Tensile Strength (min) | 75 ksi | 515 MPa |
| Yield Strength, 0.2% Offset (min) | 30 ksi | 205 MPa |
| Elongation (min) | 35% | 35% |
Stainless Steel 310 Pipe Equivalent Grades
This is a grade chart for SS 310 pipe that has all the cross-references needed for worldwide engineering projects.
| Standard / Region | Grade 310 Equivalent |
|---|---|
| USA | UNS S31000 |
| Germany / EU (EN/DIN) | 1.4841 / X15CrNiSi25-21 |
| Japan (JIS) | SUS 310 |
| China (GB) | 2Cr25Ni20 |
| UK (BS) | EN 10095 (1.4845) |
| Russian (GOST) | 20Ch25N20S2 |
| France (AFNOR) | Z12CN25-20 |
Stainless Steel 310 Pipe Industrial Applications
Industries use alloy 310 conduit: chemical processing, power generation, and heat treatment. In these industries, it is important that the material can resist oxidation at temperatures above 1000°C.
Heat Treatment & Furnace Industry
SS 310 pipe used in radiant tubes, muffle furnaces, and kiln linings for high-temperature carburising resistance.
Chemical & Petrochemical Processing
Essential for reactor piping, transfer lines, and catalyst systems due to superior oxidation resistance.
Power Generation & Boiler Systems
310 stainless steel pipe is applied in superheater tubing, boiler baffles, and exhaust ducting for high-temperature creep strength.
SS 310 vs 310S Stainless Steel Pipe Comparison
This comparison assists engineers and customers in selecting the appropriate high-temperature grade depending on welding specifications and operating temperatures. Grade 310 has better creep strength for heat that stays above 1000°C for a long time. Low-carbon 310S performs better in welded systems because it effectively prevents intergranular corrosion during the common cycles of heating and cooling.
| Feature | Stainless Steel 310 | Stainless Steel 310S |
|---|---|---|
| UNS Designation | UNS S31000 | UNS S31008 |
| Carbon Content (Max) | 0.25% | 0.08% |
| Creep Strength | Higher in extreme heat | Slightly Lower |
| Welding Risk | Higher risk of sensitisation | Reduced carbide precipitation |
| Max Service Temp | Continuous above 1000°C | Better for cyclic heating |
| Best Application | High-strength furnace parts | Welded piping & fabrications |
Shipping & Packaging
Heavy-duty wooden boxes Packing
We strictly follow seaworthy export handling standards to protect 310 pipe from transit damage, moisture ingress, and surface contamination during long-distance dispatch.
- Heavy-duty wooden boxes with moisture barrier lining
- HDPE stretch film wrapping on all bundles
- Plastic end caps on threaded and plain-end pipes
- Silica gel desiccants to minimize moisture exposure
- ISPM-15 fumigated wooden packaging for export
Pipe Bundle Yard Staging
Container End-Cap Protection
Wrapped Export-Ready Bundles
We Export Worldwide
Sachiya Steel International supplies stainless steel products to major industrial markets across North America, Europe, the Middle East, Asia and Africa with export-ready documentation and logistics support.
