ASTM A240 Stainless Steel 202 Sheet Specification

The specifications of Stainless Steel 202 Sheet, including thickness, standards and length, are mentioned in the table below.

Parameter Details
Standard ASTM A240 / ASME SA-240
Thickness 0.01 mm to 200 mm
Width 1000, 1219, 1500, 1800, 2000, 2500, 3000, 3500 mm
Length 2000, 2440, 3000, 5800, 6000 mm
Form Sheet, Plate, Strip, Coil
Finish 2B, 2D, BA, No.1, No.4, No.8, Mirror, Hairline, Matt

Stainless Steel 202 Sheet Dimensions

The dimensions of Stainless Steel 202 Sheet are mentioned in the table in detail.

Parameter Details
Thickness Range 0.5 mm to 25 mm
Width Range 1000 mm to 3500 mm
Length Options 2000 mm, 2440 mm, 3000 mm, 5800 mm, 6000 mm
Custom Sizes Available as per client specification

SS 202 Sheet Weight Chart

Weight formula: Thickness (mm) × Width (m) × Length (m) × 7.80. Density of SS 202 is 7.80 g/cm³.

Thickness (mm) Width (mm) Length (mm) Weight (kg)
1.0 1220 2440 23.2
2.0 1220 2440 46.4
3.0 1500 3000 105.3
5.0 1500 6000 351.0

Available Surface Finishes

SS 202 Sheet comes in multiple finishes:

  • 2B (cold rolled, bright) Stainless Steel 202 Sheet
  • BA (bright annealed) Stainless Steel 202 Sheet
  • No.1 (hot rolled) Stainless Steel 202 Sheet
  • No.4 (brushed/satin) Stainless Steel 202 Sheet
  • No.8/8K (mirror) Stainless Steel 202 Sheet
  • Hairline, matt, and embossed Stainless Steel 202 Sheet

Stainless Steel 202 Sheet Price Per Kg

Stainless Steel 202 Sheet costs about INR 120–150 per kg (USD 1.40–1.75 per kg), depending on thickness, size, finish, order quantity, and market rates. SS 202 Sheet costs 20–30% less than SS 304 Sheet because of lower nickel content: 4.0–6.0% versus 8.0–10.5%. Contact Sachiya Steel International for the latest SS 202 sheet price per kg.

Chemical Composition of Stainless Steel 202 Sheet

The chemical composition of Grade 202 stainless steel, along with its proportion in percentage, is listed below. Manganese at 7.50–10.00% is the defining element of this 200-series grade. It stabilises the austenitic structure while replacing the nickel required in 300-series alloys.

Carbon C
Max 0.15%
Manganese Mn
7.50 – 10.00%
Silicon Si
Max 1.00%
Phosphorus P
Max 0.060%
Sulphur S
Max 0.030%
Chromium Cr
17.0 – 19.0%
Nickel Ni
4.0 – 6.0%
Nitrogen N
Max 0.25%

Mechanical Properties of Stainless Steel 202 Sheet

The mechanical properties of Stainless Steel 202 Sheet, including elongation and yield strength, are listed below. The 620 MPa tensile strength exceeds SS 304’s 515 MPa minimum. This makes 202 SS Sheet a good choice for light structural and architectural use in areas with low corrosion.

620 (90)
MPa (ksi)
Tensile Strength
260 (38)
MPa (ksi)
Yield Strength
40%
(min)
Elongation
Property Metric Imperial
Tensile Strength (min) 620 MPa 90 ksi
Yield Strength (min) 260 MPa 38 ksi
Elongation (min) 40% 40%
Request a Quote for SS 202 Sheet Request a Quote

Equivalent Designations for Stainless Steel 202 Sheet

International designation equivalent to SS 202 Sheet, including UNS and Werkstoff Nr., is listed in the table below.

Standard Designation
UNS S20200
AISI 202
Werkstoff Nr. 1.4373
EN X12CrMnNiN17-7-5
JIS SUS 202
Chinese (GB) 1Cr18Mn8Ni5N

Industrial Applications of Stainless Steel 202 Sheet

Stainless Steel 202 Sheet serves 3 major sectors that require high-performance and resistance to corrosion.

Food & Kitchen Equipment

SS 202 Sheet is widely used in kitchen sinks, restaurant equipment, and cookware.

Architectural & Interior Applications

Elevator panels, door frames, window trims, handrails, and wall cladding commonly use 202 stainless steel sheet.

Automotive & Railway

The automotive sector uses SS 202 Sheet for trim components, hose clamps, and brackets, railway coach interiors and panelling.

Stainless Steel 202 vs 304 Sheet: Comparison for Buyers

This table compares SS 202 and SS 304 sheets in cost, strength, composition, corrosion resistance, and ideal application environments.

Property / Factor SS 202 Sheet SS 304 Sheet
Cost 20–30% lower Higher
Nickel Content 4.0–6.0% 8.0–10.5%
Tensile Strength ~620 MPa ~515 MPa
Corrosion Resistance Moderate Superior (especially chlorides)
Suitable Environment Indoor, low-corrosion settings Food-grade & chemical exposure
Key Advantage Cost-effective, higher strength Better corrosion resistance

Shipping & Packaging

Main export packaging setup Heavy-duty wooden boxes Packing
Export Packaging Standard

We strictly follow seaworthy export handling standards to protect stainless steel 202 sheets from transit damage, moisture ingress, and surface contamination during long-distance dispatch.

  • Heavy-duty wooden boxes with moisture barrier lining
  • HDPE stretch film wrapping on all bundles
  • Edge and corner protection with plastic padding
  • Silica gel desiccants to minimize moisture exposure
  • ISPM-15 fumigated wooden packaging for export
shipping preparation Sheet Bundle Yard Staging
Shipping packaging Sheet Bundle Edge Protection
Shipping stock Wrapped Export-Ready Bundles

We Export Worldwide

Sachiya Steel International supplies stainless steel products to major industrial markets across North America, Europe, the Middle East, Asia and Africa with export-ready documentation and logistics support.

  • USA flagUSA
  • Canada flagCanada

Frequently Asked Questions:

What is the price of 202 Grade SS Sheet per kg? +
In India, standard-size SS 202 Sheets usually cost about INR 120–150 per kg. The exact price changes based on the sheet’s thickness, surface finish, quantity and mill origin. Request a quote for current rates.
Which is better for my application: SS 202 or SS 304 Sheet? +
SS 202 sheet costs 20–30% less than SS 304 and has higher tensile strength (620 MPa vs 515 MPa). In SS 304 higher nickel content provides better corrosion resistance. Use SS 202 for indoor use and SS 304 for food-grade or chemical environments.
What are the standard sizes of SS 202 Sheet? +
SS 202 sheets are available in thicknesses from 0.01 mm to 200 mm, widths from 1000 to 3500 mm, and lengths from 2000 to 6000 mm. Custom sizes are also available on request.
What is the working temperature range for SS 202 Sheet? +
SS 202 Sheet works well at very low temperatures and up to about 400°C. Continuous service above this range isn’t recommended.
What surface finishes are available for SS 202 Sheet? +
Available finishes include 2B, 2D, BA, No.1, No.4, No.8 (mirror/8K), hairline, satin, matt, embossed, and chequered. PVC coating is available to protect sheets during shipping.
How do I calculate the weight of the SS 202 Sheet? +
The formula is: Weight (kg) = Thickness (mm) × Width (m) × Length (m) × 7.80. A 2 mm sheet measuring 1220 × 2440 mm weighs approximately 46.4 kg.
Is SS 202 Sheet magnetic? +
SS 202 Sheet is generally non-magnetic in the annealed condition. Cold working can induce slight magnetism. It’s less magnetic than 400-series ferritic grades.
Can the SS 202 Sheet be welded? +
SS 202 Sheet can be welded using conventional fusion methods and resistance welding. Oxyacetylene welding isn’t recommended. Post-weld heat treatment may be needed to prevent corrosion between grains of the metal.
