Hardox 450 Plate Manufacturer and Supplier

Hardox 450 plate is a quenched and tempered abrasion-resistant steel plate with a nominal hardness of 425 to 475 HBW. This 450 BHN wear plate is made to special standards, ensuring it has a tough outer surface and consistent hardness throughout, engineered for consistent through-thickness hardness.

Hardox 450 Plate composition restricts carbon to a maximum of 0.26%, precisely balanced with manganese, chromium, nickel, and molybdenum to regulate hardenability. The material exhibits high performance with a tensile strength ranging from 1,400 to 1,550 MPa and a yield strength of around 1,250 MPa. Moreover, the minimum elongation is maintained at 10%, guaranteeing essential structural ductility for rigorous engineering applications.

Sachiya Steel International is a certified supplier, stockist, and exporter of Hardox 450 steel plate, with a warehouse in Mumbai, India. With over 20 years of experience and ISO certifications, including 9001, 14001, and 45001, we keep a ready-to-ship inventory of 1,500 to 2,000 metric tonnes in various plate thicknesses.

What sets this grade apart from generic AR450 is the tighter dimensional tolerance, cutting-edge delivery, and primed blasted surface finish that reduces fabrication cost on site. Available thicknesses range from 3 mm to 80 mm, with standard widths up to 2,440 mm and lengths up to 7,315 mm. Custom cutting is available on request. Hardox 450 plate serves wear-critical roles in mining, construction, recycling, agriculture, and transportation. It's also weldable and bendable when the correct procedures are followed.

This page covers:

Specification
Pricing
Chemical Composition
Mechanical Properties
Equivalent Materials
Industrial Applications
Grade Comparison
Shipping & Packaging
Frequently Asked Questions

Specifications of Hardox 450 Plate

Hardox 450 Plates, a world-leading abrasion-resistant steel with unusual hardness and toughness, have the following material specifications.

Property	Details
Hardness (HBW)	425 – 475 Brinell (as per EN ISO 6506-1)
Thickness Range	3.0 mm to 80 mm
Width	Up to 2440 mm
Length	Up to 7,315 mm
Delivery Condition	Quenched (Q) or Quenched & Tempered (QT)
Processing	Excellent Cold Bending, Welding, and Machining

Hardox 450 Plate Sizes and Dimensions

Refer to the table below for the standard stock dimensions and thickness ranges available for Hardox 450 plates.

Parameter	Dimensional Range
Thickness	3 mm to 80 mm (0.125" to 3.0")
Standard Width	Up to 2,440 mm (96")
Standard Length	Up to 7,315 mm (288")
Customisation	Precision custom cutting to buyer-specified dimensions

Standard Plate Dimensions

Dimension	Metric	Imperial
Thickness	3 mm to 80 mm	0.125 in to 3.0 in
Width	up to 2,440 mm	up to 96 in
Length	up to 7,315 mm	up to 288 in

Plate Weight per Square Metre by Thickness

Weight per square metre is calculated as thickness (mm) multiplied by 7.85 (steel density factor for 7,850 kg/m3).

Thickness (mm)	Weight (kg/m2)
6	47.1
10	78.5
16	125.6
20	157.0
25	196.3
40	314.0

Hardox 450 Plate Price

Thinner gauges and custom cutting cost more than 250 INR/kg ($3.00/kg) for ordinary plates. Hardox 450 prices depend on thickness, specific profiles, and market changes. Custom quotes provide the most precise project pricing. Extended wear life and faster manufacturing offset the 15–30% cost differential over generic AR450. Contact our sales team for a current quote on your needs.

Hardox 450 Chemical Composition

The table below presents the maximum allowable elemental composition for Hardox 450 plate by heat analysis.

Low carbon content paired with boron microalloying allows deep hardenability without sacrificing weldability. Chromium and molybdenum contribute to temper resistance and through-thickness hardness uniformity.

Carbon C

Max 0.26%

Silicon Si

Max 0.70%

Manganese Mn

Max 1.60%

Phosphorus P

Max 0.025%

Sulphur S

Max 0.010%

Chromium Cr

Max 1.40%

Nickel Ni

Max 1.50%

Molybdenum Mo

Max 0.60%

Boron B

Max 0.005%

Hardox 450 Mechanical Properties

The following table lists the key mechanical properties of Hardox 450 plate under standard delivery condition.

1400 - 1550

MPa

Tensile Strength

~1,250 (181)

MPa (ksi)

Yield Strength

(min)

Elongation

425 to 475

HBW

Hardness

Property	Value	Unit
Hardness (Brinell)	425 to 475	HBW
Tensile Strength	1,400 to 1,550	MPa
Yield Strength (typical)	~1,250 (181)	MPa (ksi)
Elongation (min, A5)	10	%

Hardness (Brinell, Rockwell, Vickers Conversion)

The nominal Brinell hardness of 425 to 475 HBW converts to approximately 45 to 50 HRC on the Rockwell C scale. In Vickers units, this spans roughly 446 to 500 HV. Buyers specifying hardness in different scales can use the conversion below for material verification.

HBW	HRC	HV (approx.)
425	45	446
450	47	473
475	50	500

Request a Quote for Hardox 450 Plate Request a Quote

Hardox 450 Equivalent Materials

The table below lists equivalent 450 BHN abrasion resistant plate designations from manufacturers worldwide.

Designation Type	Grade / Brand Name
AFNOR (France)	Creusabro 4800
DIN (Germany)	Dillidur 450
DIN (Germany)	XAR 450
JIS (Japan)	JFE EH450
JIS (Japan)	Abrex 450
AS (Australia)	Bisalloy 450
EN (Europe)	Quard 450

Hardox 450 Plate Industrial Applications

Hardox 450 wear plate serves 4 major industry sectors where abrasion causes premature equipment failure. The 450 BHN hardness extends component service life 2 to 5 times over mild steel in the same application.

Mining and Quarrying

This plate lines excavator buckets, crusher feed chutes, screen decks, and hopper walls in hard-rock mining operations. Rock and ore abrasion at these contact points wears mild steel within weeks.

Construction and Earthmoving

Hardox 450 steel plate is fitted to bulldozer blades, grader cutting edges, loader bucket floors, and concrete mixer drums. Ground-engaging components benefit directly from the 450 BHN surface hardness.

Recycling and Waste Handling

Shredder liners, sorting screens, and compactor chambers in scrap metal and waste processing facilities use this plate. Mixed waste streams containing metal, glass, and stone create extreme sliding abrasion.

Transportation and Dump Bodies

Dump truck bodies, trailer floors, and tipper bins are a high-volume application for 450 Brinell plate. Reduced plate thickness (compared to mild steel) lowers vehicle dead weight and increases payload capacity.

Hardox 450 vs AR450 and Other Wear Steels

Hardox 450 competes with generic AR450 and adjacent hardness grades. The three comparisons below cover the most common selection decisions: generic AR450, Hardox 400, and Hardox 500.

Hardox 450 vs. Generic AR450

Feature	Hardox 450	Generic AR450
Core Hardness	Engineered for consistent through-thickness hardness	Not Guaranteed
Edge Condition	Precision Cut Edges	Often Mill Edges
Surface Finish	Primed and Blasted	Standard Mill Scale
Fabrication Cost	Lower (Less Prep)	Higher (More Prep)
Initial Price	15% – 30% Premium	Baseline

Hardox 450 vs. Hardox 400

Feature	Hardox 450	Hardox 400
Hardness (HBW)	425 – 475	370 – 430
Wear Resistance	Superior	Standard
Formability	Moderate	Excellent
Welding Ease	Standard	High
Primary Use	High Abrasion	Cold Forming/Bending

Comparison: Hardox 450 vs. Hardox 500

Feature	Hardox 450	Hardox 500
Hardness (HBW)	425 – 475	470 – 540
Abrasion Profile	High	Extreme/Severe
Weldability	Flexible	Restricted
Formability	Good	Limited
Value Focus	Fabrication Versatility	Maximum Wear Life

Shipping & Packaging of Hardox 450 Plate

Heavy-duty wooden boxes Packing

Export Packaging Standard

We strictly follow seaworthy export handling standards to protect Hardox 450 Plate from transit damage, moisture ingress, and surface contamination during long-distance dispatch.

Heavy-duty wooden boxes with moisture barrier lining
HDPE stretch film wrapping on all bundles
Edge and corner protection with plastic padding
Silica gel desiccants to minimize moisture exposure
ISPM-15 fumigated wooden packaging for export

Plate Bundle Yard Staging

Plate Bundle Edge Protection

Wrapped Export-Ready Bundles

We Export Worldwide

Sachiya Steel International supplies Wear Resistant products to major industrial markets across North America, Europe, the Middle East, Asia and Africa with export-ready documentation and logistics support.

USA
Canada

Frequently Asked Questions:

What are the standard Hardox 450 Plate sizes and dimensions? +

Hardox 450 plate is available in thicknesses from 3 mm to 80 mm, widths up to 2,440 mm, and lengths up to 7,315 mm. Custom sizes are available on request.

How much does Hardox 450 plate cost per Kg? +

Plate thickness and market shifts drive Hardox 450 costs, typically averaging 250 INR/kg ($3.00/kg). Give us your specs for a formal quote. We’ll calculate a price based on your exact measurements and the bulk discount you need.

Is Hardox 450 Plate bendable? +

Hardox 450 plate offers good cold bending properties for an abrasion-resistant grade. Minimum bend radius varies with plate thickness and orientation relative to the rolling direction.

What is the recommended welding procedure for Hardox 450 Plate? +

Select low-hydrogen E70xx or ER70S-6 wire for a robust weld. Preheat the steel between 75 and 200°C, adjusted for thickness, and closely monitor the temperature. Always keep your interpass temperature below 225°C to prevent any structural issues.

How do you drill and machine a Hardox 450 Plate? +

Drilling Hardox 450 requires carbide-tipped tools at reduced speeds with high feed rates and a constant coolant supply. Work hardening occurs rapidly if cutting speed is too high or feed too light.

What is the Rockwell hardness of Hardox 450 Plate? +

Hardox 450 has a Brinell hardness of 425 to 475 HBW, which converts to approximately 45 to 50 HRC on the Rockwell C scale.

How do you calculate Hardox 450 Plate Weight? +

The formula is: Weight (kg) = Length (m) x Width (m) x Thickness (mm) x 7.85. Steel density for this plate is approximately 7,850 kg/m3.

Does Hardox 450 Plate rust? +

Hardox 450 is a low-alloy carbon steel and will corrode without surface protection. It ships in a primed and blasted condition. Additional coating or painting is recommended for corrosive or outdoor environments.

What are the best practices for machining and drilling Hardox 450? +

Hard material requires carbide-tipped tools. Machine slower than mild steel and drill with high feed rate and steady coolant to avoid work hardening. For profiling, switch from mechanical sawing to plasma or oxy-fuel cutting for better efficiency.
