Stainless Steel Cold Rolled Sheet Specification
The four grades share one specification and differ only in chemistry, so the sizes, finishes and tolerances below apply equally to all of them.
| Property | Details |
|---|---|
| Standard | ASTM A240 / ASME SA240 |
| Grades | 202, 304, 316, 430 |
| Thickness | 0.3 mm to 6.0 mm |
| Width | 1000 mm, 1219 mm, 1250 mm, 1500 mm; up to 2000 mm on request |
| Length | 2000 mm, 2438 mm (8 ft), 3048 mm (10 ft), 6000 mm, or cut to length |
| Sheet Sizes | 4 ft × 8 ft (1219 × 2438 mm), 4 ft × 10 ft (1219 × 3048 mm), custom |
| Forms | Sheet, Coil, Strip, Slit Coil |
| Surface Finish | 2B, BA (bright annealed), No. 4 brushed, Hairline, No. 8 mirror |
| Condition | Cold rolled, annealed, descaled and skin passed |
| Edge Condition | Mill Edge, Slit Edge |
Stainless Steel CR Sheet Sizes and Gauges
Gauge is the number most enquiries arrive in, so the table below gives it alongside both thickness units and both weight units. Stainless is 8.00 g/cm³, which means every millimetre of thickness is 8.00 kg per square metre, and the rest of the table follows from that. The gauges below run 26 to 11, which is 0.476 mm to 3.175 mm of the 0.3 mm to 6.0 mm stocked band. Mill edge is the strip as it came off the slitter. Slit edge is trimmed to a set width, and it is the one to order when the edge will be welded or left on show.
| Gauge | Thickness (in) | Thickness (mm) | Weight (kg/m²) | Weight (lb/sq ft) |
|---|---|---|---|---|
| 26 GA | 0.019 | 0.476 | 3.81 | 0.78 |
| 24 GA | 0.025 | 0.635 | 5.08 | 1.04 |
| 22 GA | 0.031 | 0.794 | 6.35 | 1.30 |
| 20 GA | 0.038 | 0.952 | 7.62 | 1.56 |
| 18 GA | 0.050 | 1.270 | 10.16 | 2.08 |
| 16 GA | 0.062 | 1.588 | 12.70 | 2.60 |
| 14 GA | 0.078 | 1.984 | 15.88 | 3.25 |
| 12 GA | 0.109 | 2.778 | 22.22 | 4.55 |
| 11 GA | 0.125 | 3.175 | 25.40 | 5.20 |
Finishes on Stainless Steel Cold Rolled Sheet
The finish is rolled and polished in at the mill rather than put on afterwards, and it is the main reason to buy cold rolled instead of hot rolled stainless sheet. 2B is the default on everything held here, and the other four are ordered by name.
| Finish | How it looks | What it is ordered for |
|---|---|---|
| 2B | Smooth and matte with a low sheen | The standard supply finish. Tanks, panels, and anything to be formed or welded |
| BA (bright annealed) | Reflective straight off the mill, with no polishing | Appliance fronts and trim that need a bright face without polishing cost |
| No. 4 | Directional satin, brushed one way | Worktops, splashbacks and lift interiors |
| Hairline (HL) | Finer and longer brush lines than No. 4 | Architectural panels and door furniture |
| No. 8 mirror | Polished until it reflects clearly | Feature panels, signage and decorative columns |
All five start from the same cold rolled, annealed and descaled strip, so the grade underneath is unchanged by the choice. What changes is the cost and the way the face behaves in service. A brushed or mirror finish shows fingerprints and fine scratches that a 2B face hides, which is why 2B stays the default on anything that will be worked rather than looked at.
Cold Rolled Stainless Steel Sheet Price
CR SS sheet is priced on the alloy in it before anything else, and nickel is the dearest part of that alloy. The bands below are the ones quoted on each grade page, converted at ₹85 to the dollar.
| Grade | Price in India (per kg) | Export price (per kg) |
|---|---|---|
| SS 202 CR Sheet | from ₹145 | from $1.71 |
| SS 304 CR Sheet | ₹180 to ₹300 | $2.12 to $3.53 |
| SS 316 CR Sheet | ₹260 to ₹376 | $3.06 to $4.42 |
| SS 430 CR Sheet | ₹130 to ₹450 | $1.53 to $5.29 |
Within a grade, thickness and order size move the figure. Thin gauges cost more per kilo than heavy ones because the mill makes more passes per tonne, and a brushed or mirror face adds to both. Nickel and molybdenum are bought on the open market, which is why the 304 and 316 figures are quoted for the week rather than the year.
Where SS CR Sheet Is Used
Cold rolled stainless steel sheet goes into work where the surface is part of the product. Four kinds of job account for most of what leaves here, and the grade is usually settled by the room the sheet ends up in rather than by the forming it has to take.
Food and Catering Equipment
Worktops, splashbacks, sink units and tank linings are 304 work, usually in No. 4 so that wear marks blend into the brushed grain instead of standing out against it. The face takes a hot caustic wash down without pitting, which is the test a catering kitchen applies every night.
Architectural and Interior Panels
Lift car interiors, column cladding, signage and door furniture are chosen on finish before anything else, which is why Hairline and No. 8 mirror sell into this work. 304 covers most inland jobs and 316 takes over within reach of salt air.
Appliance and White Goods Panels
Cooker fronts, extractor hoods and fridge doors are mostly 430, partly on cost and partly because it is magnetic, so door seals and mounting magnets hold against it. The duty is dry and indoors; wet or chlorinated service belongs to the austenitic grades.
Process Plant and Chloride Service Panels
Tank skins, guards and ducting in chemical, pharmaceutical and coastal plant are 316, bought for the 2.00 to 3.00% molybdenum rather than for the finish. 2B is the usual face, because the panel is there to work and not to be looked at.
Grades of Cold Rolled Stainless Steel Sheet
What separates the four is the alloy, not the rolling. All of them are cold rolled to the same tolerances and sold in the same finishes. The choice comes down to how much chromium, nickel and molybdenum the job needs, and whether the sheet is allowed to be magnetic.
| Property | 202 CR | 304 CR | 316 CR | 430 CR |
|---|---|---|---|---|
| Structure | Austenitic | Austenitic | Austenitic | Ferritic |
| Chromium | 17.0 to 19.0% | 17.5 to 19.5% | 16.0 to 18.0% | 16.0 to 18.0% |
| Nickel | 4.0 to 6.0% | 8.0 to 10.5% | 10.0 to 14.0% | 0.75% max |
| Molybdenum | None | None | 2.00 to 3.00% | None |
| Tensile strength, min | 620 MPa | 515 MPa | 515 MPa | 450 MPa |
| Magnetic | No, when annealed | No, when annealed | No, when annealed | Yes, always |
Stainless Steel 202 CR Sheet
Stainless Steel 202 is an austenitic chromium-nickel-manganese alloy that puts manganese in place of part of the nickel, which is what makes it the cheapest of the three austenitic grades. ASTM A240 sets its tensile minimum at 620 MPa, the highest here, and 202 cold rolled sheet goes into household fittings, sink units and interior trim where the air stays dry.
Stainless Steel 304 CR Sheet
Stainless Steel 304 is the grade most enquiries mean when they say stainless, and it covers general indoor, architectural and food work without argument. It carries 17.5 to 19.5% chromium and 8.0 to 10.5% nickel, welds and forms readily, and 304 cold rolled sheet is the one held in the widest range of finishes.
Stainless Steel 316 CR Sheet
Stainless Steel 316 adds 2.00 to 3.00% molybdenum, and that is the whole reason to pay the difference over 304. Molybdenum holds the passive film together where chlorides would otherwise break through it, so 316 cold rolled sheet is what goes into coastal work, chemical plant and anything washed down with chlorinated water.
Stainless Steel 430 CR Sheet
Stainless Steel 430 is ferritic rather than austenitic, so it carries almost no nickel, stays magnetic in every condition and resists oxidation to 815°C in continuous service. Its tensile minimum is 450 MPa, below the austenitic three, so it bends less far before it cracks. Appliance panels and dry indoor trim are where 430 cold rolled sheet earns its place, rather than wet or chloride service.
Shipping & Packaging
Heavy-Duty Wooden Box Packing
A 2B or polished face marks if anything is dragged across it, so bright and brushed sheets leave with PVC film on the show side and the film stays put until the panel is fitted. Bundles are interleaved so that no two faces rub against each other on the way.
- Heavy-duty wooden boxes or strapped bundles, with moisture barrier lining
- LLDPE stretch film wrapping on all bundles
- Edge and corner protection with plastic padding
- Silica gel desiccants to minimise moisture exposure
- ISPM-15 compliant wooden packaging for export
